Support Software for Network Compatible Drivers

New: Ver.4.18.1.0.0.0

Last Updated on: 9/9/2024

*Windows 8 - 11, please contact Technical Support for older versions

Support software for use with Network Compatible Drivers.

EDS File for BLV Series R Type Drivers (CANOpen)

EDS files for BLV Series R Type Drivers are available for download.

EtherNet/IP™ EDS File for AZ Series Compatible Drivers

Rev1.00

Last Updated on: 7/19/2024

An EDS file has been prepared to allow EtherNet/IP™ compatible products to be used more easily.



Add-On Instructions (AOI) for AZ Series EtherNet/IP™ Compatible Drivers

Rev1.3 U1.0

Last Updated on: 3/16/2020

Add-On Instructions (AOI) for AZ Series EtherNet/IP driver. Use the AOI to save programming time or make it easier to read or write your data parameters in AZ Series driver.

• Move Command
• Operation Position / Speed
• Current Settings or Accel/Decel Settings
• Monitoring
• Direct Data Operation (changing data on the fly)
• AOI User Guide for AZ Series Included



PROFINET GSD File for AZ Series Compatible Drivers

Rev2.4

Last Updated on: 6/29/2022

An GSD file has been prepared to allow PROFINET compatible products to be used more easily.



PROFINET GSD File for AZX Series Compatible Drivers

Rev2.43

Last Updated on: 8/19/2024

An GSD file has been prepared to allow PROFINET compatible products to be used more easily.



EtherNet/IP™ EDS File for AZX Series Compatible Drivers

Rev1.00

Last Updated on: 9/19/2023

An EDS file has been prepared to allow EtherNet/IP™ compatible products to be used more easily.



Applicable Products

αSTEP Closed Loop Stepper Motors

Series	Product Type	Communication Cable Type
AZ series	Built-in positioning function type	USB cable
	Mini driver
AZ series multi-axis driver	EtherCAT drive profile support
	MECHATROLINK-Ⅲ compatible
	SSCNET III/H compatible



Stepper Motors

Series	Product Type	Communication Cable Type
CVD series	RS-485 Communications Type	USB cable
	Fully Closed-Loop Type



Brushless DC Motors

Series	Product Type	Communication Cable Type
BLE2 series	-	USB cable
BLV R Type series	-	USB cable
BLH series	Digital setting type	USB cable
	RS-485 communication type



Servo Motors

Series	Product Type	Communication Cable Type
AZX series	EtherNet/IP	USB cable



Linear Actuators

Series	Product Type	Communication Cable Type
Equipped with EAS series α STEP AZ series	Built-in positioning function type	USB cable
EZS series α STEP AZ series installed	Built-in positioning function type	USB cable
EZS series Clean room compatible αSTEP AZ series installed	Built-in positioning function type	USB cable
EZSH series α STEP AZ series installed	Built-in positioning function type	USB cable
EAC series α STEP AZ series installed	Built-in positioning function type	USB cable
DR series α STEP AZ series installed	Built-in positioning function type	USB cable
DRS2 series α STEP AZ series installed	Built-in positioning function type	USB cable
Equipped with L series α STEP AZ series	Built-in positioning function type	USB cable
EH series α STEP AZ series installed	Built-in positioning function type	USB cable



Hollow Rotary Actuators

Series	Product Type	Communication Cable Type
DGⅡ series STEP AZ series installed	Built-in positioning function type	USB cable

MEXE02 Support Software, v3.72

Last Updated on: 4/5/2024

*Windows 8 - 10, please contact Technical Support for older versions

MEXE02 Support Software for Standard Products,
for Ethernet/IP™, Ethernet or EtherCAT products please refer to appropriate tab.

Cable for connection to PC required for data setting software (CC05IF-USB)

**Standard USB communications cable (not supplied) required for AZ Series products.

• Create motion profiles and execute them immediately
• Full system configurability
• I/O monitoring
• Waveform capture
• Drag and drop programming capability
• Upload/Download programs and parameters
• Built-in terminal function
• Linked motion creator

Applicable Products

Brushless DC Motors

Series	Product Type	Communication Cable Type
BLE series	Standard type/Type with electromagnetic brake	CC05IF-USB
	CC-Link Ver.1.1 compatible
	RS-485 communication type
BXⅡ series	Position control mode
	Speed ​​control mode
BLV series	Standard type/Type with electromagnetic brake	CC05IF-USB



αSTEP Closed Loop Stepper Motors

Series	Product Type	Communication Cable Type
AR series	Pulse input type	CC05IF-USB
	Built-in positioning function type
	DeviceNet compatible



Stepper Motors

Series	Product Type	Communication Cable Type
RKⅡ series	Built-in positioning function type	CC05IF-USB
CRK series	Built-in positioning function type
PKA series	Built-in positioning function type



Servo Motors

Series name	Communication cable
NX series	CC05IF-USB



Linear Actuators

Series	Product Type	Communication Cable Type
Equipped with EAS series α STEP AR series	Pulse input type	CC05IF-USB
	Built-in positioning function type
EZS series Clean room compatible αSTEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
EZSH series α STEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
EAC series α STEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
DRLⅡ series	Built-in positioning function type	CC05IF-USB



Hollow Rotary Actuators

Series	Product Type	Communication Cable Type
DGⅡ series STEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
DGⅡ series RKII series installed	Built-in positioning function type	CC05IF-USB



Network Converters

Product Type	Communication cable
CC-Link Ver.2 compatible	USB cable
CC-Link Ver.1.1 compatible	CC05IF-USB
MECHATROLINK-II compatible
MECHATROLINK-Ⅲ compatible
EtherCAT compatible

Programming Software MRC Studio

v4.2.0.1

Last Updated on: 7/17/2024

MRC Studio is a programming software that supports everything from startup to maintenance. A computer can be used to create operation programs, edit various parameters, perform teaching, and monitor various statuses.

Windows 10 Ver 1607 or later.

*After programming MRC01 with MRC Studio Ver.3.0.0.0 or later, do not program with earlier versions of MRC01. Data read/write cannot be executed normally, and the data in MRC01 may be changed.

Communication Cable:
Prepare a USB cable (commercially available) with the following specifications.
Standard: USB 2.0 (full speed)
Cable: Length: 3m or less, Shape: A to mini-B

Device Driver:
Device drivers are automatically installed when you install MRC Studio. Use it only if the device driver could not be installed with MRC Studio.
The device driver download file contains 32-bit and 64-bit versions. Please choose according to your environment.
ORIENTAL MOTOR USB Common Virtual COM Port Driver Windows 10

MRC Studio Simulator:

Updated: 5/14/2024

MRC Studio Simulator is available for users who wish to test before purchasing the MRC01 robot controller. With the MRC Studio Simulator, you can create, execute, teach, set home, and operate programs while viewing the robot's 3D graphics. The download file contains sample data files for each robot type, so you can try it immediately after installing the MRC Studio Simulator.
Ver.4.0.0.0
Windows 10 Ver.1607 or later

Note:

- The MRC Studio Simulator may operate differently than the product version. Also, communication with the MRC01 robot controller is not possible. When connecting with MRC01, please use the product version software.



Fuji Electric FRENIC Loader Software for Inverters / VFD



CRK Stored Program Controller (CRK5xx-KP) Motion Creator Software, v2.02

Last Updated on: 7/10/2012

• Create motion profiles and execute them immediately
• Full system configurability
• I/O monitoring
• Multi-axis control
• Waveform capture
• Drag and drop programming capability
• Upload/Download programs and parameters
• Built-in terminal function
• Linked motion creator
